Total Magnification
40x-1600x
Digital Camera Systme
3.1M pixels, sensor size:6.55*4.92mm, field:18.2mm,
Vision proportion:91%
5.0M pixels,sensor size:5.70*4.28mm, field:15.84mm,
Vision proportion:79%
8.0M pixels,sensor size:5.70*4.28mm, field:15.84mm,
Vision proportion:79%
Eyepiece
WF10x/20mm, High point,diopter adjustable
WF16x/16mm, High point,diopter adjustable
Head
Compensation brinocular head, 30° inclined, 360° rotatable,
interpupillary distance 55-75mm, infinity optical system
Nosepiece
4 Holes revolving nosepiece, inward
Objective
ICCF Infinity Opitcal HC Plan Achromatic 4x
ICCF Infinity Opitcal HC Plan Achromatic10x
ICCF Infinity Opitcal HC Plan Achromatic 40x (Spring)
ICCF Infinity Opitcal HC Plan Achromatic 100x (Spring, Oil )
Focusing
Coaxial coarse and fine focusing knob, with tension
adjustable ring and rack stop. coarse focusing range 20mm, fine focusing
graduation is 0.001mm
Stage
Double layer mechanical stage, size 145x188mm,
moving range 76x54mm Condenser
Abbe condenser N.A.=1.25
Light Source
Kohler illumination,halogen lamp 6V30W and 3W
LED can interchange easily Power
Input AC90-240Vm,output DC 5V/6A
