Viewing Head: Compensation Free Binocular Head, Inclined at
30°, Interpupillary Distance 55 – 75mm.
Eyepiece: Wide Field Eyepiece WF10X/18.
Objective: Achromatic objective 4x, 10x, 40x, 100x.
Nosepiece: Quadruple nosepiece.
Stage: Double Layers Mechanical Stage 140X140mm / 75X50mm.
Condenser: NA1.25 Abbe Condenser with Iris Diaphragm and Filter.
Focusing: Coaxial Coarse & Fine Focus Adjustment System,
Range 24mm, Fine Division 2μm.
Illumination: Halogen Lamp 6V20W, Brightness Adjustable.
