Description

• 3.5 Pyrogen-Free Reagent Grade Water
• Maximum 7.0/hour Distilled Water Production Capacity
• 20 HDPE Water Storage Reservoir
• Completely Automated Water Production Mechanism
• Germicidal 8 watt UV Radiation Immersion Lamp
• Optional Soft Water System Prevent Scale in the Water Pathways

Specifications
Capacity 6.0 Litre / Hour
Heater high Quality Quartz Sheated Heater
UV Lamp Imersion Type with Glass Tube 8 watts
Pump Max. Pressure 120 psi / 2.5 Litre/min
Reservoir 20 Litre with HDPE Carboy
Filteration Prefilter andactive Carbon Filter 10 inch
Glassware Borosilicate 3.3 (Pyrex) Glass
Safety Device Water float level sensor, inlet water pressure switch, and distillate receiving
level sensor.
Operation Fully Automatic Operation
Dimensions: 750 (W) x 485 (D) x 1270 (H) mm
Electric Power: 110V, 60Hz or 220V, 50/60Hz
