Eyepiece:
Wide Field Eyepiece WF10X/18
Wide Field Eyepiece
EWF10X/20
Nosepiece:
Outward-facing Quadruple
nosepiece
Objective:
Semi-Plan Achromatic Objective
4x.10x. 40x. 100x
Plan Achromatic Objective 4x.
10x. 40x. 100x.
Infinite Semi-Plan Achromatic
Objective 4x.10x. 40x. 100x.
Infinite Plan Achromatic
Objective 4x. 10x. 40x. 100x
Condensor:
NA1.25 Abbe Condenser with
Iris Diaphragm and Filter
Stage:
Double Layers Mechanical
Stage 140X140mm,
movement :75X50mm
Focusing:
Coaxial Coarse & Fine Focus
Adjustment System,
Range 24mm, Fine Division 2μm
Illumination:
6V2W halogen lamp, brightness
adjustable
Digital System:
Digital heads:
Finite System digital head
NLCD3
Infinite System digital head
NLCD4
LCD: 2.5” color TFT LCD
display, and 100o maximum
elevation angle, pivoting screen
Resolutions: 2048×1536 /
1600×1200 / 1280×1024
Output: USB, AV, S-Video and
Audio are available, can display
images both on TV and PC
Sensor: Build-in 3.14 Mega
pixels CMOS Chip
EMS Memory: Internal Storage
32M Internal Storage Memory
SD Interface: Support highcapacity
SD card, upto 3GB
Operating system: Windows
2000, XP and Vista.
