Viewing Head: Compensation Free Binocular
Head at 30°, 360° Rotatable.
Eyepiece: WF10X/18 with Scale of Crosshair and
0.1mm, Eyepiece WF10X/18.
Objective: Strain-free Achromatic Objective
4x, 10x, 40x, 60x.
Nosepiece: Backward quadruple nosepiece,
Center adjustable.
Analyzer: Rotatable Analyzer with
Graduation 0° – 90°.
Bertrand Lens: Bertrand Lens,
Sliding in/out of Optical Path.
Optical Compensator: λSlip (firstclassred) ,
1/4 Slip, Quartz Wedge.
Revolving Round Stage: Diameter 160mm, 3600
Rotatable and Graduated in 10 Increments,
Minimum Resolution 6’ when Using Vernier Scale.
Condenser: N.A.1.25 Abbe Condenser with Iris
Diaphragm & Filter.
Polarizer: Sliding in/out of optical path, located on
the top of collector.
